EMI & ENVIRONMENTAL SHIELDING
As versatile as they come.
One of our bestsellers - through rapid prototyping, our team designs FIP gaskets that reduce the amount and the size of screw holes to achieve smaller overall packaging. In addition, our FIP can be placed on PCB traces as thin as 0.5mm, creating more space for board components.
EMI SHIELDING
CONDUCTIVE FIP GASKET
Filled with Nickel/Graphite, Ag/Cu, Ag/Al, Ag/Ni or other conductive particles, providing excellent electrical conductivity.
SPECIALIZED FIP GASKET
Unique conductive gasketing materials for specialty applications:
ULTRA-SOFT
ENVIRONMENTAL FIP GASKET
Silicone and fluorosilicone Form-in-Place gaskets designed for protection up to an IP68 rating.
PRECISION IS OUR TOP PRIORITY -
Micro-Dispensing Technology
Can accurately place beads as small as 0.25 mm high. Through vigorous testing and rapid prototyping, we work with customers to overcome any accuracy challenge.
Best-In-Class Shielding Solutions
Our shielding solutions are consistently tested with outstanding results.
Let’s get down to the details.
A MUST-HAVE TO COMBAT HARSH ENVIRONMENTS
FLUOROSILICONE FIP
A specialty gasket engineered for aerospace, satellite, land and sea-based applications. Flurosilicone is a superior alternative with all the benefits of silicone and designed for harsh corrosive environments, including exposure to:
Salt fog
UV and ozone
JP-10 jet fuel
Polar solvent
Polyalphaolefin (PAO)
Meets NASA outgassing requirements:
TML，0.06%
CVCM，0.01%
WVR，0.03%
ISO 9001 and AS 9100 Certified. ITAR Registered.
Cybersecurity Maturity Model Certification (CMMC) / SP NIST 800-171 Compliant. Learn More →
GOOD THINGS COME IN TWO’S
MAXCOMBO FIP MATERIALS
Ever want the best of both worlds?
Our specialty MaxCombo™ family is designed to do just that.
MaxEEC™
Environmental Seal + Electrically Conductive FIPA single gasket that provides both functions, thus provides additional space-saving and weight reduction.
MaxTEC™
Thermally & Electrically Conductive FIP
Increases heat transfer and allows for more efficient conductivity while providing RF shielding between cavities.
ISO 9001 and AS 9100 Certified. ITAR Registered.
Cybersecurity Maturity Model Certification (CMMC) / SP NIST 800-171 Compliant. Learn More →
get down to the details
Click on any part number to view the data sheet.
| Typical Properties | EMI SHIELDING GASKETS | ENVIRONMENTAL SEALING GASKETS | EMI SPECIALTY GASKETS | |||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Part Number | F5301 | F5304 | F5314 | F5221 | F5321 | F5521 | F6023 | F6031 | F6003 | F6012 | F6081 | F7101 MaxTEC™ | F5381 Chemical Resistance | F5382 Chemical Resistance | F9304 MaxEEC™ |
|
| Elastomer Binder | Silicone | Silicone | Fluorosilicone | Silicone | Fluorosilicone | Silicone | ||||||||||
| Conductive Filler | Ni/Gr | Ag/Cu | Ni/Gr | Ag/Al | N/A | Special Fillers | Ni/Gr | |||||||||
| Curing System | Thermal | Moisture | Moisture | Thermal | Thermal | Thermal | ||||||||||
| Hardness (Shore A) | 75 | 30 | 35 | 40 | 70 | 55 | 25 | 20 | 40 | 20 | 40 | 55 | 60 | 75 | 35 | |
| Resistance * (Ohm) |
0.05 | 0.08 | 0.1 | 0.05 | 0.09 | 0.07 | 0.05 | 0.08 | 0.10 | 0.05 | 0.09 | 0.10 | 0.15 | 0.06 | 0.06 | |
| Shielding Effectiveness | > 100 dB @ 200 Mhz - 40 GHz | N/A | > 100 dB @ 200 Mhz - 40 GHz | |||||||||||||
| Minumum Bead Height | 0.3 mm | 0.3 mm | 0.6 mm | 0.3 mm | 0.6 mm | 0.3 mm | 0.5 mm | 0.3 mm | 1 mm | 0.3 mm | ||||||
| Features | Small bead application with superior adhesion | Ultrasoft, low compression force application | Soft, reboundable, low compression force application for higher frequencies | Superior conductivity with higher compression capabilities | Preferred material for metalized plastics, RTV version of F5301 | High corrosion resistance in harshest environments | Ideal for weather resistant applications | RTV version of F6012 with low compression force | UV Resistant | A foam based material that is highly compressable | Resistance to polar solvents, fuels, chemicals, and salt spray/fog with low outgassing | Over 2x the thermal conductivity of standard FIP EMI gaskets | Resistance to polar solvents, fuels, oil additives, chemicals, and salt spray/fog with low outgassing | Excellent EMI shielding performance with superior environmental sealing property | ||
